Produkty / Testery telekomunikacyjne / Testery 10G Ethernet / Albedo Ether10.DuaLoop

⇒ Urządzenie zapętlające do 10GbE
⇒ Pętla L1/L2/L3/L4
⇒ Podówjne porty SFP/SFP+ oraz RJ-45
⇒ Ekran dotykowy
⇒ Zasilanie bateryjne

Ether10.DuaLoop jest przenośnym urządzeniem zapętlającym ruch na interfejsach do przepustowości 10Gbit/s. Urządzenie posiada podwójne porty elektryczne/optyczne które mogą pracować niezależnie w trybie pętli L1-L4. Urządzenie zapętla pakiety Ethernet/IP pozwalając na wykonanie testów wydajnościowych takich jak RFC2544 oraz eSAM (Y.1564). Interfejsy optyczne urządzenia realizowane są poprzez adaptery SFP+.


Ether10.DuaLoop


Główne cechy urządzenia:

  • Dwa porty elektryczne RJ-45: 10BASE-T, 100BASE-TX and 1000BASE-T
  • Dwa porty optyczne SFP/SFP+: 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, 10GBA SE-SW, 10GBASE-LW, 10GBASE-EW, 1000BASE-T, 1000BASE-SX, 1000BASE-LX, 1000BASE-ZX, 1000BASE-BX, 100BASE-FX, 100BASE-TX, 10BASE-T
  • Ekran dotykowy
  • Zasilanie bateryjne
  • Odporna I wytrzymała obudowa
  • Pętla na L1/L2/L3/L4
  • Wsparcie Q-in-Q
  • Wsparcie MPLS
  • Skanowanie MAC/IP/VLAN/QinQ
  • Zaawansowane liczniki: do 8 filtrów na MAC, IP, TCP/IP
  • Sygnalizacja zdarzeń poprzez diody LED
Aplikacje:
  • Certyfikacja QoS oraz SLA
  • Zapętlanie ruchu dla BERT, RFC-2544, Y.1564

Opcje hardware/software do zamówienia:

KOD Opis
AT.E10DL.HH Ether10.Dualoop 10 Gb/s Ethernet / IP Traffic Reflector. Battery operated, touchscreen. Smart Gigabit Ethernet L1-L4 loopback function. Dual 10/100/1000 Mb/s RJ-45 electrical ports, dual 10G/1000/100 Mb/s optical ports (SFP+), traffic analysis, error statistics and filters. Includes AC/DC adapter, transportation bag and one RJ-45 patch cable. SFP+ transceivers not included.
AT.E10DL.IPV6 Ipv6 statistics. Decoding and analysis of Ipv6 datagrams. Ipv6 traffic statistics. Ipv6 packet filtering. Top Ipv6 source and destination addresses (with Network Search option)
AT.E10DLP.NS Network Search. Automatic detection of up to 16 most frequent streans listed by IPV4, VLAN and MAC
AT.VNC.RC Graphical Remote Control. Based on VNC for Windows and Linux. Ethernet/IP remote control that duplicates the tester graphical user interface in a remote computer.
AT.SNMP.RC SNMP Remote Control and Automation. Based on SNMP protocol allows user to control the tester remotelly using SNMP queries.
AT.Wi-Fi.RC Wi.Fi USB. Remote Control wireless interface to be used together with VNC.
[REQUIRES: AT.VNC.RC]
AT.10GS.SFP SFP Adapter 10 Gb/s, 850 nm, MMF, 300 m reach, w/ DDM, Duplex LC, 0 - 70C
AT.10GL.SFP SFP Adapter 10 Gb/s, 1310 nm, SMF, 2 km reach, w/ DDM, Duplex LC, 0 - 70C
AT.10GZ.SFP SFP Adapter 10 Gb/s, 1550 nm, SMF, 40 km reach, w/ DDM, Duplex LC, 0 - 70C
AT.1000Sx.SFP Short haul SFP adapter. 1.25 Gb/s SFP, 850 nm, MMF, 500 m reach, with DDM, Duplex LC, 0 – 70ºC.
AT.1000Lx.SFP Long haul SFP adapter. 1.25 Gb/s SFP, 1310 nm, SMF, 20 km reach, with DDM, Duplex LC, 0 – 70ºC.
AT.1000Zx.SFP Very long haul SFP adapter. 1.25 Gb/s SFP, 1550 nm, SMF, 80 km reach, with DDM, Duplex LC, 0 – 70ºC.
AT.100Fx.SFP Optical 100 Mb/s SFP adapter. 125 Mb/s SFP, 1310 nm, MMF, 2Km reach, with DDM, SGMII, Duplex LC,  0 – 70ºC.
AT.20 Car charger. Power adapter to charge the test unit from car battery.
AT.Lipo.Batt Additional Lipo battery.


Dane techniczne
